Bartop Premium with Curved Pedestal Kit

The Bartop Premium with Curved Pedestal Kit combines our Premium bartop with a curved pedestal, creating a full standing arcade cabinet. The bartop and pedestal are manufactured separately and sold together: the bartop is placed on top of the pedestal once both are assembled.

CNC precision-built piece by piece on 16mm board with an eccentric nut assembly system, ensuring a precise and solid build. Includes a VESA bracket with 75 and 100 holes fixed to both side panels using angle brackets, compatible with most monitors on the market.

We recommend pairing it with a 21.5″ monitor to make full use of the screen opening.

Technical specifications

Total height (bartop + pedestal)	155 cm
Width	55 cm
Depth	43 cm
Monitor opening (W × H)	52 × 34 cm
Recommended monitor	21.5″
Board thickness	16 mm
Assembly system	Eccentric nuts
Monitor mounting	VESA bracket with 75 and 100 holes, fixed to both side panels using angle brackets
U-molding required	9 metres of 16 mm
Manufacturing	CNC precision

Special features

Independent bartop and pedestal — Both pieces are manufactured and assembled separately. The bartop is placed on top of the pedestal. Optionally you can add the screw fixing to join them rigidly.

Lower door with latch — Quick access to the interior of the control panel without needing to disassemble the cabinet. Ideal for maintenance or component changes in the CPO.

Acrylic slots — The Premium features integrated slots to house the marquee and screen acrylics without any adhesive or additional fixing required.

Two-player control panel

Upper CPO: 1 joystick + 6 buttons per player
Front CPO: 1-1-1 layout

Customise your Bartop Premium with Curved Pedestal Kit

From the product configurator you can tailor the cabinet to your preferences before adding it to the cart. Below we explain each option.

Material

The cabinet is built with the material you select. All materials are 16mm thick.

Raw MDF — MDF board with no surface finish. Included in the base price. Ideal if you plan to paint the cabinet. If you would rather apply vinyl, choose a laminated board: vinyl will stick to MDF, but you need to sand it first with fine sandpaper and clean it very thoroughly.
White Laminated Chipboard — White laminated surface on both faces. No paint or primer needed. Vinyl adheres directly.
Black Laminated Chipboard — Dark finish that contrasts beautifully with vivid vinyl designs. The classic arcade look.

Button hole size

Choose the diameter based on the buttons you plan to install.

28 mm — American standard. Compatible with American-style buttons and Lorenzo PSL-L.
30 mm — Japanese standard. Compatible with Japanese-style buttons, Sanwa, chrome and illuminated translucent buttons.

If you already have buttons, check the diameter before choosing. Feel free to ask us if you have any doubts.

Speakers

No holes — The cabinet ships without speaker perforations.
3″ holes — Holes are drilled, no speakers included.
3″ holes with 10W speakers — Includes a pair of 5 W speakers with amplifier, power supply and wiring.
3″ holes with 20W speakers — Includes a pair of 10 W speakers with amplifier, power supply and wiring. More powerful sound than the 10W option.

If you select any option with holes, you can also add decorative grilles in various colours: Black, Grey, White, Gold, Silver, Chrome, Blue and Red.

Vinyl

No — The cabinet is delivered without vinyl.
Yes — You will access a selector with multiple designs available.

If you select vinyl, also choose the finish:

Matte — More resistant to fingerprints and scratches.
Gloss — More vibrant and saturated colours.

U-Molding

U-molding is the plastic edge trim applied to the board edges. It serves an aesthetic purpose and protects the cabinet edges. The Bartop Premium with Curved Pedestal Kit requires 9 metres of 16mm u-molding to cover both the bartop and the pedestal.

No u-molding — If you already have some or prefer to source it separately.
Black / White / Blue / Red / Green / Yellow / Pink — 9 metres available in various colours.

Accessories

Socket with power switch	On/off power button integrated into the cabinet.
4-outlet power strip	Distributes power to all internal components. Ready to connect to the socket with power switch.
Joystick recess	Routing on the CPO so the joystick base adds extra height to the joystick. Ideal for Eurojoystick 2 and Sanwa or Japanese-style joysticks without an extension shaft.
Marquee + screen acrylics	Allows vinyl to be applied to the marquee and screen, enabling a monitor bezel effect. They slot directly into the cabinet grooves.
Upper control panel acrylic (CPO)	Covers and protects the upper control panel with a transparent finish.
Lower control panel acrylic	Same for the lower control panel.
Pinball holes	One hole on each side of the cabinet in pinball style.
Bartop-pedestal screw fixing	4 through-holes are drilled to insert 4 bolts that join the bartop base to the pedestal top. The assembly becomes rigid and looks like a single piece.
