Isolation Relay 5V-12V for Arcade Electronic Coin Acceptors

3,95€

Solid-state relay module that protects your arcade encoder by isolating the electronic coin acceptor circuit (12V) from the USB logic signal (5V). No moving parts, with indicator LEDs and screw terminals. Compatible with Zero Delay, Xin Mo, IPAC and Raspberry Pi.

Buy this item and get 3 OmniCoins - a value of 0,03€

Category: Coin acceptors

Isolation Relay for Arcade Electronic Coin Acceptors

What exactly does it do?

This solid-state relay module protects your arcade encoder by isolating the electronic coin acceptor circuit (12V) from the USB logic signal (5V). Prevents ground loops and voltage spikes that can damage your encoder board.

Key Features

Complete electrical isolation between 12V coin circuit and 5V logic
Solid-state design: no moving parts, silent operation
LED indicators for input/output status
Screw terminals: no soldering required
Integrated flyback diode for inductive load protection
Compact size: 44×18×17 mm, 13 g

Technical Specifications

Input voltage	5V DC (logic side) / 12V DC (load side)
Switching capacity	10A / 250V AC
Channels	1 (NO/NC/COM)
Dimensions	44×18×17 mm
Weight	13 g

Compatibility

Works with Zero Delay USB Encoder, Xin Mo, IPAC, IPAC2, and Raspberry Pi GPIO projects. Not required for Pandora Box boards as they already include coin input isolation.

Ideal for custom bartop and arcade cabinet builds where you want to add a real coin mechanism without risking your encoder board.
